ABB IMDSM04BAILEY CONTROLSMODULE
Multiplexer and Input State Circuitry
The eight conditioned input signals from the Schmitt-trigger inverters are time-division multiplexed to use a single 16-bit counter. A channel counter increments the multiplexer. Each channel processes in turn every 7.2 microseconds (every 7.8 microseconds if a slave expander bus transaction takes place). The channel counter spends about 900 nanoseconds processing each input before moving onto the next channel. When the multiplexer selects a channel, an 8-bit shift register stores the input state (0 or 1). The register shifts for each channel sample. The 8-bit register will hold the previous input state for each complete count. The MFP may read the present input state.
Our Advantage
ICS Triplex T8461,ICS Triplex T8311,ICS Triplex T8431,ICS Trusted Triplex T8310
All Yokogawa CP401-10,SCP461-51,Yokogawa CP451-10,ALR121-S50 Are Availabe
We Also Sell Emerson DeltaV EPRO Yokogawa Products,Call US Now.
