Original New GE Bently Nevada 3500/33 16-Channel Relay Module in Stock
Overview
The 16-Channel Relay Module is a full-height module that provides 16 relay outputs. Any number of 16-Channel Relay Modules can be placed in any of the slots to the right of the Rack Interface Module. Each output of the 16-Channel Relay Module can be independently programmed to perform needed voting logic. Each relay utilized on the 16-Channel Relay Module includes "Alarm Drive Logic". Programming for the Alarm Drive Logic uses AND and OR logic, and can use alarming inputs (Alert and Danger statuses), Not- OK, or individual PPLs from any monitor channel or any combination of monitor channels in the rack. Users program this Alarm Drive using the 3500 Rack Configuration Software to meet the specific needs of the application
Ordering Considerations
The 3500/33 requires 3500 Rack Configuration software, version 3.3 or later
The 3500/33 requires 3500 Data Acquisition software, version 2.40 or later • The 3500/33 requires 3500 Data Display software, version 1.40 or later
When used with a 3500/93 LCD Display module, the 3500/93 will require firmware revision P or later. • When used with a 3500/94 VGA Display module, the 3500/94 will require firmware revision C or later
Specifications
| Part No. | 3500/33 |
| Power Consumption | 5.8 watts typical. |
| Relays Type | Single-pole, double-throw (SPDT) relays |
|
Physical Main Module Dimensions (Height x width x depth) |
241 mm x 24.4 mm x 242 mm (9.50 in. x 0.96 in. x 9.52 in.) |
| Physical Main Module Weight | 0.7 kg (1.6 lb.) |
| I/O Module Dimensions |
241 mm x 24.4 mm x 99.1 mm (9.50 in. x 0.96 in. x 3.90 in.). |
| I/O Module Weight | 0.4 kg (1.0 lb.) |
