Invensys Foxboro FBM205 P0914XG Four Redundant 0 to 20 mA DC Analog Output Channels
Introduction
The FBM205, 0 to 20 mA I/O Interface (Redundant) contains four redundant 0 to 20 mA dc analog input channels and four redundant 0 to 20 mA dc analog output channels. The inputs/outputs are galvanically isolated from other channels and ground. A redundant pair of the modules combine to provide redundancy at the Fieldbus Module (FBM) level, with field I/O wired to one common termination assembly (see Figure 1). Each module independently attempts to hold the output(s) at its specified output value(s), and each independently reports its observed value of the inputs.
Key features of the FBM205P0914XG
1. Four redundant 20 mA dc analog input channels
2. Four redundant 20 mA dc analog output channels
3. Each input and output channel is galvanically isolated
4. Compact, rugged design suitable for enclosure in Class G3 (harsh) environments
5. Execution of an analog input application program that provides conversion time and configurable options for Rate of Change Limits
6. Configurable options in the modules for output security include Fail-Safe Action
7. High accuracy achieved by sigma-delta data conversions for each channel
8. Termination Assemblies (TAs) for locally or remotely connecting field wiring to the FBM205
9. Redundant loop power on FBM powered transmitters
10. 3-tier termination assembly for per channel internally and/or externally loop-powered transmitters.
