F3330 HIMA Digital Output Card safety related
Description
resistive load or inductive load up to 500 mA (12 W), lamp connection up to 4 W, with integrated safety shutdown, with safe isolation, no output signal with break of the L- supply requirement class AK 1 ... 6The module is automatically tested during operation. The main test routines are: – Reading back of the output signals. The operating point of the 0 signal read back is ≤ 6.5 V. Up to this value the level of the 0 signal may arise in case of a fault and this will not be detected – Switching capability of test signal and cross-talking (walking-bit test).
The safety-related F3330 controller is a compact system located in a metal enclosure with 24 digital inputs, 8 digital outputs, 2 counters and 8 analog inputs. The controller is available in 3 model variants for SILworX and 3 model variants for ELOP II Factory, see Chapter 3.2. All variants are described in this manual. The device is suitable for mounting in Ex-zone 2, see Chapter 4.1.5. The device has been certified by the TÜV for safety-related applications up to SIL 3 (IEC 61508, IEC 61511 and IEC 62061), Cat. 4 (EN 954-1) and PL e (EN ISO 13849-1). Further safety standards, application standards and test standards are specified in the certificate available on the HIMA website.
Our Supply Range
1. Allen-Bradley 1756/1769/1771/1785 Series (1769-L30ERMS,1769-L30ER-NSE,1769-L33ERMS,1756-L61,1756-L62,1756-L73）
2. ABB 800xA/Bailey INFI90/DSQC/ Series (07KT98 WT98,07KT97 WT97,DSQC679,IMASI23,IMDSO14...)
3. Bently Nevada 3500/3300 Series (3500/42M ,3500/22M,3500/95.3500/15)
4. Schneider Modicon Series (140CPU65150,140CPU67060,140CRA ,140CPS)
5. GE IC693/IC697/IC698/IS200/DS200 Series (IC693CPU363,IC697PWR711,369-HI-0-0-0-0,DS200ADGIH1AA)
6. SIEMENS MOORE/S5 Series (6ES7 cards,6ES5,6DD,6DP)
7. Westinghouse/OVATION (1C31194G01,1C31197G01,5X00106G01,1C31125G02...)
8. ROSEMOUNT: (3008,3664,3805E.3704E,3700A 4351B...)
9. FOXBORO (FCP270,FBM203,FBM204,FBM217,FMB231...)
About us
Our office is located in Xiamen Fujian, China, cooperate with original manufacturer directly; Equipped with a professional sales team, own engineer for technical support and good after-sale service;Large inventory with original product quality for fast delivery. These help us become as a strong supporter of our clients: providing solution for the end-user, and also ensuring profits for the re-seller.
Hima Main Serise:
1. CPU:F8650X, F8650E, F8641
2. Power Distribution Module:F7130A, F7130, F7131, F7133
3. Communication MODULE Coprocessor MODULE；F8621A, F8627X, F8628, F8628X
4. Input Module：F3221, F3222, F3223, F3224, F3236, F3237,F6208, F6214, F6215, F6216, F6216A,F6217, F6220, F6221
5. OUTPUT MODULE:F3330, F3331, F3332, F3333, F3334,F3322, F7126, F6705,F1DI1601, F3DIO8/801, F2DO1602, F3DIO20/802,F3AIO8/401, F60GEH01, F60PS01, F60DIO24/1601, F60DI3201,Z7116, Z7126, Z7127, Z7138, Z7128
6. I/O bus link module block:F7553
