HIMA F3322 DIGITAL OUTPUT MODULE
Description
-resistive or inductive load up to 500 mA (12 W), lamp connection up to 12 W
- with safe isolation -no output signal at break of the L
- supply
Block diagram
The module is automatically tested completely during operation. The main test routines are: - Switch on and switch off cability - Crosstalk of the input circuits by walking 0 test - Function of the input filters - Correct function of the module - Short circuit and wire break of the sensor line Function of LEDs are not tested. Appertaining softw. building block: HB-RTE-. (for current version refer to the description of the operating system)
Hima Main Serise:
1. CPU:F8650X, F8650E, F8641
2. Power Distribution Module:F7130A, F7130, F7131, F7133
3. Communication MODULE Coprocessor MODULE；F8621A, F8627X, F8628, F8628X
4. Input Module：F3221, F3222, F3223, F3224, F3236, F3237,F6208, F6214, F6215, F6216, F6216A,F6217, F6220, F6221
5. OUTPUT MODULE:F3330, F3331, F3332, F3333, F3334,F3322, F7126, F6705,F1DI1601, F3DIO8/801, F2DO1602, F3DIO20/802,F3AIO8/401, F60GEH01, F60PS01, F60DIO24/1601, F60DI3201,Z7116, Z7126, Z7127, Z7138, Z7128
6. I/O bus link module block:F7553
