HoneywellMU-TDID72 51303928-100 Digital Input 24 FTA Module In Stock
Description
All connections to and from the process are made to Field Termination Assemblies (FTA). Compression-type termination blocks (that can accept wire sizes as large as 14 AWG or ~1.6 mm) are available for all FTAs. Screw-type termination's can also be provided for most FTAs as shown in Table 1 in the “Specifications” section. The FTAs are connected to the I/O processors by cables that can be up to 50 meters in length. Three sizes of FTAs are used as shown in this table. Twenty-four Vdc transmitter and digital inputs sense power connections are provided through the standard FTA cable
HoneywellField Termination Assemblies FTA Modules
| FTA Type | Model Number | Non-CE Compliant Part Number | CE Compliant Part Number |
| HLAI | MU-TAIH23 | N/A | 80369165-125 |
| HLAI | MU-TAIH53 | N/A | 51309138-225 |
| STI | MU-TSTX03 | N/A | 51309136-125 |
| STI | MU-TSTX13 | N/A | 51309138-125 |
| STI | MU-TSTX53 | N/A | 51309138-225 |
| AO | MU-TAOX02 | 51304476-100 | 51304476-125 |
| AO | MU-TAOX12 | 51304335-100 | 51304335-125 |
| AO | MU-TAOX52 | 51304335-200 | 51304335-225 |
| AO | MU-TAOY22 | 80366177-100 | 80366481-125 |
| AO | MU-TAOY23 | 80366177-200 | N/A |
| AO | MU-TAOY52 | 80364007-100 | 80366484-125 |
| AO | MU-TAOY53 | 80364007-200 | N/A |
| 24 Vdc DI | MU-TDID12 | 51304441-100 | 51304441-125 |
| 24 Vdc DI | MU-TDID52 | 51304441-200 | 51304441-225 |
| 24 Vdc DI | MU-TDID72 | 51303928-100 | N/A |
| 24 Vdc DI | MU-TDIY22 | 80366180-100 | 80366180-125 |
| 24 Vdc DI | MU-TDIY62 | 80364010-100 | 80364010-125 |
| 120 Vac DI | MU-TDIA12 | 51304439-100 | 51304439-125 |
| 120 Vac DI | MU-TDIA52 | 51304439-200 | 51304439-225 |
| 120 Vac DI | MU-TDIA72 | 51303930-100 | N/A |
| 240 Vac DI | MU-TDIA22 | 51304431-100 | 51304431-125 |
| 240 Vac DI | MU-TDIA62 | 51304431-200 | 51304431-225 |
| 24 Vdc Nonisolated DO | MU-TDON12 | 51304446-100 | N/A |
| 24 Vdc Nonisolated DO | MU-TDON52 | 51304446-200 | N/A |
| 24 Vdc Isolated DO | MU-TDOY22 | 80366183-100 | 80366183-125 |
