Original New HoneywellMC-TDOY22 51204160-175 Digital Output FTA Module
Description
All connections to and from the process are made to Field Termination Assemblies (FTAs). Compression-type termination blocks (that can accept wire sizes as large as 14 AWG or ~1.6 mm) are available for all FTAs. Screw-type termination's can also be provided for most FTAs as shown in Table 1 in the “Specifications” section. The FTAs are connected to the I/O processors by cables that can be up to 50 meters in length. Three sizes of FTAs are used as shown in this table. Twenty-four Vdc transmitter and digital inputs sense power connections are provided through the standard FTA cable
HoneywellField Termination Assemblies FTA Modules
FTA Model Number
Description
CE Compliant Part Number
Non-CE Compliant Part Number
MC-TDOY22
24 Vdc Isolated Digital Output with compression term
80366183-175
80366183-150
MC-TDIY22
24 Vdc Digital Input with compression terminals
80366180-175
80366180-150
MC-TDIA62
240 Vac Digital Input with fixed-screw terminals
51304431-275
51304431-250
MC-TDID12
24 Vdc Digital Input with compression terminals
51304441-175
51304441-150
MC-TDID52
24 Vdc Digital Input with fixed-screw terminals
51304441-275
51304441-250
MC-TDID72
24 Vdc Digital Input with removable-screw terminals
N/A
51303928-150
MC-TDIY62
24 Vdc Digital Input with fixed-screw terminals
80366180-275
80366180-250
MC-TDOA13
120/240 Vac Solid-State Digital Output w/comp term
51304648-175
51304648-150
MC-TDOA53
120/240 Vac Solid-State Digital Output w/screw term
51304648-275
51304648-250
MC-TDOD13
3-30 Vdc Digital Output with compression terminals
N/A
51304650-150
MC-TDOD14
3-30 Vdc Digital Output with compression terminals
51309153-175
N/A
MC-TDOD22
31-200 Vdc Digital Output with compression terminals
N/A
51304428-150
MC-TDOD23
31-200 Vdc Digital Output with compression terminals
51309154-175
N/A
MC-TDOD53
3-30 Vdc Digital Output with screw terminals
N/A
51304650-250
MC-TDOD54
3-30 Vdc Digital Output with screw terminals
51309153-275
N/A
MC-TDOD62
31-200 Vdc Digital Output with screw terminals
N/A
51304428-250
MC-TDOD63
31-200 Vdc Digital Output with screw terminals
51309154-275
N/A
MC-TDON12
24 Vdc Nonisolated Digital Output with comp term
N/A
51304446-150
MC-TDON52
24 Vdc Nonisolated Digital Output with screw term
N/A
51304446-250
MC-TDOY62
24 Vdc Isolated Digital Output with screw terminals
80364013-175
80364013-150
MC-TDOR12
120 Vac/125 Vdc Relay Digital Output with comp term
51309148-175
51304443-150
MC-TDOR52
120 Vac/125 Vdc Relay Digital Output with screw term
51309148-275
51304443-250
MC-TDOR22
240 Vac/125 Vdc Relay Digital Output with comp term
51309150-175
51304427-150
MC-TDOR62
240 Vac/125 Vdc Relay Digital Output with screw term
51309150-275
51304427-250
