Original New Honeywell TK-IAH161 Analog 16-InputModule In Stock
Overview
UB indicates the wiring layout (In this case a cable pre-wired for module TK-IAH161 and single ended current
inputs). Different letter designators are used with other IOM’s.TC-IAH161High Level Analog, 16-Input, Voltage and Current (10 V & 4-20 mA) Module
Specification
| Parameter | Specification |
| Part No. |
TK-IAH161 |
| Number of Points | 16 channels |
| Module Publish Rate | 250 msec |
|
Open Circuit Detection Typical OC Detection Time |
VoltageEven channels - Positive Full scale reading Odd channels – Negative Full scale readingCurrent – Negative Full scale reading less than 5 seconds |
|
Normal Mode Noise Rejection Common Mode Rejection |
Greater than 33 dB @ 50 Hz Greater than 60 dB @ 60 Hz 100 dB @ 50/60 Hz |
| Channel Bandwidth | 20 Hz(-3dB) |
| Calibrated Accuracy |
Better than 0.05% of range (Voltage) Better than 0.15% of range including sense resistor (Current) |
| RFI Immunity | Error of less than 2.0% of range at 10 V/m, 27 to 1000 MHz |
| Overvoltage Capability |
Continuous at room temperature (both) 30 VDC (Voltage) 8 VDC (Current) |
Honeywell DCS Experion PKS C200 , C300
Honeywell TC-IAH16I 2 Analog Output, 8-Point, Current/Voltage Module
Honeywell TC-OAV081 RTD Input, 6-Point Module (Isolated)
Honeywell TC-IXR061 24 VDC, 32-Point Discrete Output Module
Honeywell TC-ODD321 High Level Analog, 16-Input, Voltage and Current (10 V & 4-20 mA) Module
Honeywell TC-IAH161 Thermocouple Input, 6-Point Module
Honeywell TC-IXL061 Standard (non-redundant) Power Supply Modules
Honeywell TK-FPDXX2 Redundant Power System Chassis Adaptor
Honeywell TK-FXX102 Ethernet Specialty I/O Module
Honeywell TK-FTEB01 51309512-175/51403483-100 Battery Extension Module
Honeywell TK-PPD011 51309241-175/51204142-100 IOLIM (I/O Link Module), Interface for PMIO.
Honeywell TK-IOLI01 51403427-175/51309283-600 Redundancy
Honeywell TC-PRR021 Redundancy Module
Honeywell TK-PRR021 51309288-275/51309283-300 Controllers
Honeywell TC-PRS021 Controllers、C200 Control Processor
Honeywell TK-PRS021 51404305-275/51309283-200 ControlNet Interface
Honeywell TC-CCN013 CC-PDOB01
Honeywell CC-PDOB01 Analog Input, Redundant, 16 ch.Differential
Honeywell CC-TAID11 High Level Analog Input withHART
Honeywell CC-PAIX02 High Level Analog Input with Differential non-HART
