ICS Triplex T8160 Trusted TMR Interface Modules
Description
The Trusted TMR Processor is a fault tolerant design based on a Triple Modular Redundant (TMR) architecture operating in a lock-step configuration. Figure 1 shows, in simplified terms, the basic structure of the Trusted TMR Processor module. The module contains three Processor fault containment regions (FCR), each containing a Motorola Power PC series Processor and its associated memory (EPROM, DRAM, Flash ROM, and NVRAM), memory mapped I/O, voter and glue logic circuits. Each Processor FCR has voted two-out-of-three (2oo3) read access to the other two Processor’s FCR memory systems to eliminate divergent operation. The module’s three Processors store and execute the application program, scan and update the I/O modules and detect system faults. Each Processor executes the application program independently, but in lock-step synchronisation with the other two. Should one of the Processors diverge, additional mechanisms allow the failed Processor to re-synchronise with the other two. Each Processor has an interface which consists of an input voter, discrepancy detector logic, memory, and an output driver bus interface to the Inter-Module Bus. The output of each Processor is connected by the module connector to a different channel of the triplicated Inter-Module Bus.
Advantage Products
①Allen-Bradley(USA AB)Series
②Schneider(Schneider Electric)Series
③General electric(General Electric)Series
④Westinghouse Series
⑤SIEMENS Series
⑥ABB Robots. FANUC Robots、YASKAWA Robots、KUKA Robots、Mitsubishi Robots、OTC Robots、Panasonic Robots、MOTOMAN Robots.
⑦Westinghouse: OVATION System、WDPF System、MAX1000 system spare parts.
Conversion、I/O Signal processing、Data communication systems?Digital-to-Analogue
⑧Invensys Foxboro I/A Series system，FBM（I/O）SCS、Trapezoidal logic control、Accident recalling、DAC
Invensys Triconex: Redundant fault-tolerant control system、Most modern fault-tolerant controller based on Triple Modular Redundancy (TMR) architecture.
⑨Siemens：Siemens MOORE，?Siemens Simatic C1，Siemens CNC system.
Best Quality Assurance
1.High quality
2.Prompt Delivery
3.We provide a large number brand-name parts.
4.We have experienced staff and extensive test facilities.
5.There are many goods in stock.
6. We only provide the original new items, 100% make sure the best quality!
Feel free to contact us
New Low Price!
If you have any question or need any help,please contact me DIRECTLY.I will do what i can to help you.
We believe our products are excellent. We trust you will be satisfied with your purchase.
When you are satisfied with our products and services, please give us positive feedback.
If there is a problem, please contact us immediately through any email request
