Invensys Triconex 8312 Power Modules in Tricon systems
InvensysPower ModulesIntroduction
Each Tricon chassis is equipped with two Power Modules—either one is fully capable of running the Tricon at full load and rated temperature. Each Power Module can be replaced online.The Power Modules, located on the left side of the chassis, convert line power
to DC power appropriate for all Tricon modules. Terminal strips for system grounding, incoming power and hard-wired alarms are located on the lower left corner of the backplane. Incoming power should be rated for a minimum of 240 watts per power supply.
InvensysPower ModulesSpecifications
| Power Module Model | Tricon8310 | Tricon8311 | Tricon8312 |
| Chassis Type | Main/Expansion/RXM | Main/Expansion/RXM | Main/Expansion/RXM |
| Nominal Voltage | 120 VAC/VDC | 24 VDC | 230 VAC |
| Input VAC @ 47-63 Hz | 85–140 | n/a | 185–285 |
| Input VDC | 95–180 | 22–31 | n/a |
| Fuse Rating and Type | 5 amps, time-delay | 15 amps, time-delay | 2.5 amps, time-delay |
| Output Hold Time(nominal to 0 volts) | 20 ms minimum | 2.8 ms minimum | 20 ms minimum |
| Diagnostic Indicators | PASS, FAULT, ALARM, TEMP,BAT LOW | PASS, FAULT, ALARM, TEMP,BAT LOW | PASS, FAULT, ALARM, TEMP,BAT LOW |
