Honeywell TC-IXL061 TDC 3000 Thermocouple Input Controller In Stock
Introduction
Honeywell's newest Universal I/O module, based on Universal Channel Technology, reduces or eliminates marshalling. More importantly, it allows immediate configuration without the need for additional hardware. Click on the Demo tab to view videos describing how this new technology can reduce marshalling and equipment needed.
Specification
| Part No. | TC-IXL061 |
| Number of Points | 6 channels plus 1 cold junction channel |
| Nominal Input Voltage Ranges |
-12 mV to +78 mV -12 mV to +30 mV (high resolution range) |
| Supported Thermocouple Types | B, E, J, K, R, S, T, N, C |
| Resolution | 16 bits (1.4V typical), 0.70V on high resolution range |
| Common Mode Rejection | 120 dB @ 60 Hz, 100 dB @ 50 Hz |
| Module Update Rate for All Channels | 50 milliseconds |
| Settling Time to 5% of Full Scale | Less than 80 milliseconds |
| Open Circuit Detection Open TC Detection Time | Upscale reading 5 seconds typical |
| Channel Bandwidth | 0 to 15 Hz (-3 db) |
| Normal Mode Noise Rejection | 60 dB @ 60 Hz |
| Spare CJR Thermistor Model Number |
TC-CJRT01 (part no. 51109433-100) |
| Isolation Voltage Channel to channel User to system | 100% tested at 2546 VDC for 1s 100% tested at 2546 VDC for 1s |
| Connection Terminal Blocks | TC-TBNH, 20-position terminal block |
Honeywell ExperionProducts
Honeywell TC-IAH16I 2 Analog Output, 8-Point, Current/Voltage Module
Honeywell TC-OAV081 RTD Input, 6-Point Module (Isolated)
Honeywell TC-IXR061 24 VDC, 32-Point Discrete Output Module
Honeywell TC-ODD321 High Level Analog, 16-Input, Voltage and Current (10 V & 4-20 mA) Module
Honeywell TC-IAH161 Thermocouple Input, 6-Point Module
Honeywell TC-IXL061 Standard (non-redundant) Power Supply Modules
Honeywell TK-FPDXX2 Redundant Power System Chassis Adaptor
Honeywell TK-FXX102 Ethernet Specialty I/O Module
Honeywell TK-FTEB01 51309512-175/51403483-100 Battery Extension Module
Honeywell TK-PPD011 51309241-175/51204142-100 IOLIM (I/O Link Module), Interface for PMIO.
Honeywell TK-IOLI01 51403427-175/51309283-600 Redundancy
Honeywell TC-PRR021 Redundancy Module
Honeywell TK-PRR021 51309288-275/51309283-300 Controllers
Honeywell TC-PRS021 Controllers、C200 Control Processor
Honeywell TK-PRS021 51404305-275/51309283-200 ControlNet Interface
Honeywell TC-CCN013 CC-PDOB01
Honeywell CC-PDOB01 Analog Input, Redundant, 16 ch.Differential
Honeywell CC-TAID11 High Level Analog Input withHART
Honeywell CC-PAIX02 High Level Analog Input with Differential non-HART
