Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 78 × 58 mm |
| Weight | 0.93 kg |
| Frequency Range | 4 Hz to 1000 Hz |
| Natural Frequency | 4.5 Hz ±11.1% (at 20°C, 100 kΩ load) |
| Sensitivity | 28.8 mV/(mm/s) ±2.5% (at 20°C, 100 kΩ load) |
| Damping Factor | 0.56 (at 20°C, 100 kΩ load) |
| Resistance Measuring Coil | 375 Ω ±5% |
| Insulation Resistance | >1 MΩ (test voltage 500 V AC) |
| Inductance | <90 mH |
| Capacity Against Housing | <1.2 nF |
| Maximum Lifting Current | 1.8 mA (for deviation from nominal measuring direction) |
Our products are all genuine imported goods, which can be tested, worry-free after-sales service, and quality guaranteed.
We have tens of thousands of models and tens of thousands of stocks in stock, welcome to consult!
