Product Overview:
The PR6423/00B-030 Eddy Current Sensor is designed to measure radial and axial shaft displacement, position, and speed with high precision. This sensor is widely used in critical turbomachinery applications, such as steam, gas, and hydro turbines, compressors, pumps, and fans. Paired with the CON021 Signal Converter, the sensor provides a robust solution for dynamic measurements in harsh industrial environments.
Product Specifications:
PR6423/00B-030 Eddy Current Sensor:
| Specification | Details |
|---|---|
| Measuring Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Incremental Scale Factor (ISF) | 8 V/mm (203.2 mV/mil) ±5% |
| Deviation from Best Fit Line (DSL) | ±0.025 mm (±1 mil) |
| Minimum Shaft Diameter | 25 mm (0.79”) |
| Target Material | Ferromagnetic Steel (42CrMo4/AISI 4140) |
| Protection Class | IP66, IEC 60529 |
| Operating Temperature Range | -35°C to +180°C (-31°F to 356°F) |
| Sensor Tip Material | PEEK Polyether Ether Ketone |
| Sensor Case Material | Stainless Steel |
| Cable Material | PTFE (Polytetrafluoroethylene) |
| Weight (Sensor with 1m Cable) | Approx. 100 grams (3.53 oz) |
CON021 Signal Converter:
| Specification | Details |
|---|---|
| Frequency Range | 0 to 20,000 Hz |
| Rise Time | <15 µs |
| Operating Temperature | -30°C to +100°C (-22°F to 212°F) |
| Vibration/Shock Resistance | 5g @ 60 Hz @ 25°C |
| Supply Voltage Range | -23V to -32V (Output: -4V to -20V) |
| Weight | ~120 grams (4.24 oz) |
| Housing Material | LMgSi 0.5 F22 (Aluminum) |
| Mounting | 4 Screws M5x20 (Included) |
| Connections | Lemo Plug (Transducer), Screw Terminal for Power/Output |
Product Features:
-
Non-contact Measurement: The sensor operates without direct contact, reducing wear and enhancing longevity.
-
Precision: Accurate displacement measurement with minimal deviation, ideal for turbomachinery monitoring.
-
Wide Temperature Range: Operates efficiently across extreme temperatures, from -35°C to +180°C.
-
Rugged Build: Made with durable materials like PEEK and stainless steel, ensuring reliability even in challenging conditions.
-
High Protection Class (IP66): Provides resistance to dust and water ingress, making it suitable for outdoor or industrial use.
-
Easy Integration: Compatible with various turbomachinery, offering seamless integration into existing systems.
Advantages of the Epro PR6423/00B-030 + CON021:
-
High Durability: The robust construction of both the sensor and converter ensures long-term performance.
-
Temperature Resilience: Wide operating temperature range makes it suitable for diverse environmental conditions.
-
Minimal Calibration Needed: High accuracy with minimal setup and calibration.
-
Easy Maintenance: Non-contact measurements reduce the need for frequent maintenance or calibration adjustments.
-
Advanced Safety: Intrinsically safe and non-sparking certifications ensure its use in hazardous areas.
Applications:
-
Turbomachinery: Ideal for monitoring the displacement of turbine shafts, ensuring efficient operation and early fault detection.
-
Compressors & Pumps: Monitors the performance and position of rotating machinery to ensure smooth operations.
-
Industrial Fans: Used for accurate displacement measurement to maintain the efficiency and safety of large fans.
-
Condition Monitoring Systems: Provides essential data for predictive maintenance in various industrial machinery.
Related Models in the Same Series:
| Model | Measuring Range | Linearity Error | Application |
|---|---|---|---|
| PR6423/002-030 | 2 mm | ≤ 1.0% | Standard applications in turbines and compressors |
| PR6423/005-010 | 5 mm | ≤ 1.5% | Extended range for turbines and heavy-duty applications |
| PR6423/008-020 | 8 mm | ≤ 1.5% | Larger industrial machines like pumps and fans |
| PR6423/010-050 | 10 mm | ≤ 1.5% | High-precision displacement for large compressors |
| PR6423/012-060 | 12 mm | ≤ 2.0% | Suitable for large-scale industrial machinery |
| PR6423/015-080 | 15 mm | ≤ 2.0% | High displacement measurement for power plants |
Popular Epro Models:
| Model | Measuring Range | Protection | Weight | Applications |
|---|---|---|---|---|
| PR6422 | 1 mm | IP66 | 120 grams | Light-duty turbines |
| PR6425 | 4 mm | IP66 | 100 grams | Heavy machinery monitoring |
| PR6426 | 6 mm | IP67 | 150 grams | Large industrial machinery |
| PR6424 | 8 mm | IP65 | 120 grams | Pumps and fans |
| PR6423/00B-030 | 5 mm | IP66 | 100 grams | Compressors, gearboxes |
| PR6423 | 2 mm | IP66 | 90 grams | General-purpose turbomachinery |
