Technical Specifications
| Parameter | Specification |
|---|---|
| Dimensions | 78 × 58 mm |
| Weight | 0.93 kg |
| Frequency Range | 10 Hz to 1000 Hz |
| Natural Frequency | 8.0 Hz ±1.5 Hz (at 20°C) |
| Sensitivity | 28.5 mV/(mm/s) ±5 % (at 20°C, 80 Hz) |
| Damping Factor | 0.56 (at 20°C and 100 kΩ load) |
| Transverse Sensitivity | 0.1 at 80 Hz |
| Measuring Direction | Omni-directional |
| Insulation Resistance | >1 MΩ (test voltage 500 V AC) |
| Inductance | <90 mH |
| Maximum Acceleration | 10 g peak-peak (continuous), 20 g peak-peak (short-time) |
| Temperature Range | -40 to +100°C (without packing) |
| Storage/Transport Temp. | -40 to +70°C |
