Technical Specifications
| Parameter | Specification |
|---|---|
| Model | PR6453/230-101 |
| Sensor Type | Eddy Current Sensor |
| Tip Diameter | 12.5 mm |
| Measurement Range (Position) | ±1.0 mm |
| Vibration Measurement Range | 50 to 500 µm Peak-to-Peak |
| Frequency Range | 0 to 20 kHz |
| Sensitivity | 8 V/mm (203.2 mV/mil) ±1.5% |
| Sensor Body Thread Options | M18x1, M20x1, M20x1.5, M24x1 |
| Operating Temperature Range | -35 to +180°C (-31 to +250°F) |
| Agency Approvals | CE, CSA, ATEX (Refer to converter specifications for full approval scope) |
| Minimum Shaft Diameter | ≥25 mm (0.984 in) |
| Transducer Head Diameter | 12.5 mm |
| Weight | Approx. 0.8 kg |
