Product Technical Specifications
| Parameter | Description |
|---|---|
| Dimensions | 78 × 58 mm |
| Weight | 0.93 kg |
| Operating Temperature Range | -40°C to +100°C (without packaging) |
| Relative Humidity | 0 to 100%, non-condensing |
| Protection Class | IP65 |
| Frequency Range | 4 Hz to 1000 Hz |
| Sensitivity | 28.5 mV/(mm/s) ±5% |
| Natural Frequency | 4.5 Hz ±0.75 Hz (20°C, 100 kΩ) |
| Impedance | 1875 Ω ±10% |
| Insulation Resistance | >1 MΩ |
| Maximum Vibration Amplitude | 3000 µm peak-to-peak |
| Maximum Acceleration | 10 g peak-to-peak continuous, 20 g peak-to-peak short-term |
| Signal Output | Voltage output |
Our products are all genuine imported goods in stock, which can be tested, worry-free after-sales service, and quality guaranteed.
We have tens of thousands of models and tens of thousands of stocks in stock, welcome to consult!
