Technical Specifications
| Parameter | Description |
|---|---|
| Measuring Principle | Electro-mechanical conversion for absolute vibration measurement |
| Sensitivity | 28.5 mV/(mm/s) ±5 % (20°C, 80 Hz, 100 kΩ load) |
| Damping Factor | 0.56 (20°C, 100 kΩ load) |
| Frequency Range | 10 Hz to 1000 Hz |
| Natural Frequency | 8.0 Hz ±1.5 Hz (20°C, 100 kΩ load) |
| Transverse Sensitivity | 0.1 @ 80 Hz |
| Operating Temperature Range | -20°C to +200°C (without connector) |
| Relative Humidity | 0% to 100% (non-condensing in housing and plug) |
| Protection Class | IP65 |
| Dimensions | 78 × 58 mm |
| Weight | 0.93 kg |
