Technical Specifications
| Parameter | Specification |
|---|---|
| Dimensions | 78 × 58 mm |
| Weight | 0.93 kg |
| Measuring Principle | Electro-dynamic, low tuned measuring principle for absolute vibrations |
| Measuring Direction | Omni directional (PR 9268/01x-x00), Vertical (PR 9268/20x-x00), Horizontal (PR 9268/30x-x00) |
| Frequency Range | 10 Hz to 1000 Hz (PR 9268/60x-000 and PR 9268/70x-000), 4 Hz to 1000 Hz (PR 9268/20x-x00 and PR 9268/30x-x00) |
| Sensitivity | 28.5 mV/(mm/s) ±5% (PR 9268/20x-x00, PR 9268/30x-x00) |
| Damping Factor | 0.56 (at 20°C, 100 kΩ load) |
| Transverse Sensitivity | 0.1 at 80 Hz (PR 9268/60x-000), 0.13 at 110 Hz (PR 9268/20x-x00) |
| Operating Temperature | -20°C to +100°C (standard), -20°C to +200°C (PR 9268/60x-000 and PR 9268/70x-000) |
| Protection Class | IP 65 (PR 9268/01x-x00), IP 55 (PR 9268/20x-x00, PR 9268/30x-x00), IP 65 (PR 9268/60x-000, PR 9268/70x-000) |
| Insulation Resistance | > 1 MΩ (test voltage 500 V AC) |
| Inductance | <90 mH (PR 9268/01x-x00, PR 9268/20x-x00, PR 9268/30x-x00), <160 mH (PR 9268/60x-000, PR 9268/70x-000) |
| Capacity Against Housing | <1.2 nF (PR 9268/01x-x00, PR 9268/20x-x00, PR 9268/30x-x00), Insignificant (PR 9268/60x-000, PR 9268/70x-000) |
